hello guys I hope you're having a great
0:02
time our today's video is going to be an
0:05
amazing informative and interactive one
0:08
we're going to explain in detail about
0:10
the different types of supports you'll
0:11
deal with in Structural Engineering so
0:15
let's begin our video without wasting
0:17
any time you know what supports are one
0:19
of the most critical aspects in any
0:21
structure supports provide stability and
0:24
strength in fact they're responsible for
0:26
transferring the load from one member to
0:28
the ground so if you're dealing in
0:31
structures you must know about the
0:32
different types of supports and how they
0:34
differ you might have heard about fixed
0:37
support roller support simple support or
0:39
hinge support but what are they all well
0:43
these supports are responsible for
0:45
providing restraint to the structural
0:47
member to avoid lateral or vertical
0:49
movement or deflection they're in fact
0:52
the reason why structures are able to
0:54
resist forces and transfer them safely
0:57
these supports are also responsible for
1:00
in a structural member you know what
1:02
depending on the type of support and the
1:05
member these supports can provide
1:07
restraints in various directions so
1:10
let's now start our first type of
1:12
support that is Roller support roller
1:14
supports can only resist perpendicular
1:17
forces but are free to move laterally
1:19
they allow for movement along surfaces
1:21
without resistance to horizontal forces
1:24
so you know roller supports can be in
1:26
the form of rubber bearings or gears for
1:29
instance consider consider a load on
1:30
roller skates the weight remains in
1:33
place if there is no horizontal Force
1:35
however once a horizontal force is
1:37
applied the body starts moving roller
1:39
supports are advantageous especially in
1:41
Bridge construction we generally place
1:43
roller supports at the end of bridge
1:44
spans in the form of bearing pads roller
1:48
supports are also used in frame cranes
1:50
and allow for right or left movement the
1:53
disadvantage of roller supports is that
1:55
they cannot resist horizontal forces and
1:58
there is a need for other types of
1:59
support to resist these forces in a
2:01
structure the next on our list of
2:03
supports is hinge support or pin support
2:06
pin support is pretty common in civil
2:08
engineering a pinned support does not
2:11
allow movement either vertically or
2:13
horizontally but allows for rotation
2:16
well I mean in most cases a pin support
2:19
only allows for twisting in One
2:20
Direction a good example is a human knee
2:24
it provides for turning in One Direction
2:25
but resists lateral movements it is rare
2:28
to find ideal pin support in practice
2:31
however simply supported beams are
2:32
typically regarded as pinned the support
2:35
conditions affect the distribution of
2:37
moments in the beam we also use pinned
2:39
supports in trusses and three hinged
2:42
arched Bridges the advantage of pinned
2:45
supports is that it makes it easy to
2:46
join multiple members together the
2:49
joining induces an axial force and since
2:52
the supports do not resist any moments
2:54
the design is limited to the axial
2:57
Force the only limitation of pin
3:00
supports is that a single pin support
3:02
cannot completely restrain a structure
3:04
one needs at least two pin supports for
3:06
restraint let's now move on to the next
3:08
support that is fixed support well as
3:11
the name suggests fixed supports are the
3:14
most rigid types of supports that
3:15
constrain structural members from any
3:17
movements the structural member cannot
3:19
rotate or translate in any direction a
3:22
perfect example of a fixed support is a
3:24
flag pole with a concrete base the pole
3:27
cannot move or rotate in any direction
3:30
generally for the stability of a
3:32
structure the structure should at least
3:33
have one fixed support this support
3:36
offers more excellent structural
3:37
stability than any other kind of support
3:39
fixed supports are advantageous in
3:41
situations where you can only use one
3:43
support such as caner lever beams they
3:45
ensure a structure is adequately
3:47
constrained and static sometimes the
3:49
most significant Advantage also serves
3:51
as the greatest disadvantage a structure
3:54
might need some wiggle room but fixed
3:56
supports do not allow it as concrete
3:58
gains strength in also expands therefore
4:01
an improperly designed support May
4:03
reduce durability in the structural
4:05
members brought about by the increase in
4:07
stresses the next is simple supports
4:10
simple supports are when structural
4:12
members rest on other members simple
4:14
supports are like roller supports
4:16
whereby the members can resist vertical
4:17
forces but they cannot restrain
4:19
horizontal forces an excellent example
4:22
of such a support is a plank of wood
4:24
resting on two blocks of stone the plank
4:27
can resist the vertical load but can
4:29
cannot resist the corresponding
4:31
horizontal forces if you apply a sheer
4:34
force the plank will support it but a
4:36
horizontal force will quickly get the
4:38
plank to slide off the support simple
4:40
supports are rarely used in engineering
4:42
as they pose a considerable safety risk
4:45
Engineers sometimes use these supports
4:47
are in areas that experience frequent
