just watch this viral video of gushing
0:03
water pouring through the gates rushing
0:05
down the massive Spillway surface it's
0:08
an insane sight from The Garrison Dam
0:11
spillways an earthfill embankment Dam on
0:14
the Missouri river in North Dakota or
0:16
take a look at this the water waves are
0:19
slamming against the spillway Gates
0:22
almost trying to escape over the top
0:26
mindblowing now check out this guy at
0:29
the Delwood Spillway dealing with a gate
0:31
completely buried in ice how do you even
0:35
open a Spillway like that well as soon
0:38
as he cranks it open manually the water
0:40
just obliterates the snow blasting its
0:43
way out with Incredible force and
0:46
discharge and then there's this massive
0:48
Spillway gate weighed down with an
0:50
entire load of debris watch closely as
0:54
the debris flap opens letting all the
0:57
junk shoot out along with the water
0:59
crazy right can you even imagine how
1:02
much trash we dump into our Rivers so
1:06
why am i showing you all this wild
1:07
footage it's to help you understand just
1:10
how critical spillways are for dams even
1:14
more so the gates that let water Escape
1:16
in a controlled manner they're the
1:18
unsung heroes preventing floods and
1:21
protecting communities
1:23
Downstream this is I am civil engineer
1:27
and you're watching an explainer video
1:29
on different types of Spillway Gates now
1:32
from what we've seen so far it's clear
1:34
that Spillway gates are these adjustable
1:36
barriers that manage water flow in
1:39
rivers streams or reservoirs but here's
1:42
the thing how do they actually work and
1:45
why do we see so many types of gates
1:47
each with their own unique design and
1:50
operation to get those answers stick
1:52
around till the end of this video I'm
1:54
breaking down all the different types of
1:56
gates so you'll know exactly why they're
1:58
built the way they are
2:00
no matter the type every Spillway gate
2:03
has one key job to control the amount of
2:05
water leaving the reservoir they do this
2:08
by adjusting the size of the opening
2:10
between the gate and the reservoir
2:12
simple right the smaller the opening the
2:15
less water flows out and when the gates
2:17
are shut they act like a solid wall
2:19
holding back the full force of the water
2:22
you might not realize it but we've
2:24
already covered the basics what a spill
2:27
weight gate is and its primary function
2:29
now now let's get into the real meat of
2:31
this video the different types of
2:34
Spillway Gates and their unique roles
2:36
ready to dive in let's go while looking
2:40
at the broader perspective of gate
2:41
operations we can categorize the gates
2:44
as gravity based hydraulic based and
2:47
mechanical based and it's pretty clear
2:50
the gravity based works on the principle
2:52
of gravity it uses the weight of the
2:54
gate to fall and be open it lets water
2:57
escape the gate the hydraulic base uses
3:00
hydraulic power to close and open it has
3:03
got two Chambers one that contains air
3:06
and another that contains water when the
3:09
valve is closed the air fills the water
3:11
chamber creating air bubbles pushing
3:14
down the diaphragm so as the diaphragm
3:16
is being forced to rise up it tries to
3:19
open the valve but when the valve is
3:21
open the air escapes out of the water's
3:24
chamber causing the diaphragms downward
3:26
push to sop and closes the valve again
3:30
on the other hand a mechanical based
3:32
uses some sort of motor operations to
3:35
move back and forth when the gate is
3:37
closed the motor stops moving and as the
3:39
gate is open the motor starts moving
3:42
again but mostly in the industry we
3:44
don't use this categorization rather you
3:47
might have heard terms like radio gate
3:49
flap gate slle gate Etc so let's now
3:53
discuss these one by one here is how a
3:56
slle gate looks well these gates are a
3:59
classic and versatile solution for
4:01
managing water flow in dams and
4:04
reservoirs all these Gates feature a
4:06
hinged design that allows for precise
4:09
control of water levels making them
4:11
ideal for a variety of applications by
4:14
lifting or lowering the gate water can
4:16
be released or retained with accuracy
4:19
ensuring Optimal Performance during both
4:21
normal and flood conditions their
4:23
durability and adaptability make them a
4:26
common choice in modern Water Management
4:28
Systems the next type of Spillway gate
4:31
is a slide gate the slide Gates offer a
4:34
straightforward and efficient mechanism
4:37
for water regulation using a simple
4:39
sliding action these Gates require
4:42
minimal equipment to operate making them
4:44
highly accessible and userfriendly
4:46
unlike Gates that rely on heavy lifting
4:49
mechanisms slide Gates Glide smoothly
4:53
into position providing reliable control
4:55
over water flow with ease their
4:58
Simplicity coupled with robust
5:00
construction makes them a popular choice
5:02
for smallscale water projects and
5:06
systems Crest gates are compact bottom
5:10
hinge structures designed for maximum
5:12
efficiency in areas prone to ice buildup
5:15
or floating debris these Gates operate
5:18
by tilting upward or downward to
5:21
regulate water flow making them ideal
5:23
for environments where debris passage is
5:26
crucial their sleek and functional
5:28
design ures smooth operation while
5:31
maintaining structural Integrity even
5:33
under significant hydraulic pressures
5:36
Crest gates are a testament to Smart
5:38
Engineering in challenging conditions
5:41
the next is Radio Gates also sometimes
5:44
referred to as tainter gates are
5:47
engineered for strength and efficiency
5:49
their curved design evenly distributes
5:52
water pressure reducing the strain on
5:54
gate components and allowing for easier
5:57
operation these gates are often used in
5:59
large dams where failsafe mechanisms and
6:02
robust performance are critical with
6:05
their ability to manage immense water
6:07
loads effortlessly radio gates are a
6:10
Cornerstone of modern Dam
6:12
infrastructure bear trap gates are
6:14
uniquely designed with overlapping
6:16
hinged leaves that offer exceptional
6:19
Precision in flow control this intricate
6:22
design allows for smooth operation and
6:24
excellent sealing capabilities even
6:26
under challenging conditions these gat
6:29
are commonly used in applications
6:31
requiring meticulous water management
6:34
such as locks and specialized water
6:36
diversion projects their Advanced design
6:39
makes them a standout option for areas
6:42
where precision and reliability are
6:44
Paramount now here come the drum Gates
6:48
drum gates are Hollow floating
6:50
structures hinged at the top of the dam
6:52
providing unparalleled control over
6:54
water levels by adjusting buoyancy these
6:58
Gates can be raised or lowered with
7:00
remarkable accuracy their Innovative
7:03
design ensures minimal energy
7:05
consumption while delivering precise
7:07
performance drum gates are particularly
7:10
suited for reservoirs where maintaining
7:13
exact water levels is essential for both
7:15
safety and operational
7:17
efficiency the last on our list is the
7:20
miter gate miter gates are predominantly
7:23
used in canals and waterways where they
7:26
excel at managing water flow and levels
7:29
these these Gates consist of two leaves
7:31
that meet at an angle forming a vshape
7:34
when closed this design effectively
7:37
distributes water pressure ensuring
7:39
durability and reliable performance
7:42
miter gates are a staple in navigation
7:44
systems allowing for smooth transitions
7:46
between varying water levels while
7:48
ensuring safe passage for vessels so
7:52
fellas you see the spillway Gates may
7:54
not get the spotlight but their role in
7:56
managing Water Systems is nothing short
7:58
of extreme ordinary from regulating
8:01
water flow to preventing natural
8:03
disasters they're engineering at its
8:06
finest if you enjoyed this dive into the
8:09
world of Spillway Gates give this video
8:11
a thumbs up and don't forget to
8:13
subscribe for more amazing insights into
8:16
the wonders of engineering see you in
