hello everyone do you know the Three
0:02
Gorges Dam has a massive shiplift that
0:04
allows ships weighing more than 3,000
0:07
tons to safely raise 113 M to bypass the
0:12
elevation yes that's the impact of this
0:16
massive water filled structures that is
0:18
estimated to reduce transit times and
0:20
cutting shipping costs by up to
0:23
25% but how do these massive ship lifts
0:26
work and what makes them essential in
0:28
the modern world join us as we explore
0:31
the fascinating world of shiplift and
0:33
discover how they are revolutionizing
0:35
trade transport and Engineering ship
0:38
lifts are engineering Marvels that are
0:40
transforming River navigation and making
0:42
the impossible possible but you might be
0:44
wondering why one has to lift these
0:46
ships at all well your this questions
0:50
brings us to our favorite topic dams yes
0:54
dams are considered one of the greatest
0:56
achievements of human engineering they
0:58
provide critical benefits such as
1:00
generating hydroelectric power
1:02
controlling floods and storing water for
1:04
agriculture and daily use however with
1:07
their benefits come significant
1:09
challenges particularly for River
1:11
navigation when a dam is constructed it
1:14
creates an artificial barrier in the
1:17
river dividing it into two distinct
1:19
sections the Upstream Reservoir where
1:22
water levels rise dramatically and the
1:24
downstream flow which is significantly
1:27
lower the difference in elevation can
1:29
range from a few meters to hundreds of
1:31
meters depending on the Dam's size and
1:34
purpose for ships traveling along these
1:36
Rivers this elevation difference becomes
1:38
an insurmountable obstacle effectively
1:41
cutting the river in half and disrupting
1:44
navigation this disruption is not just
1:46
an inconvenience it can have
1:48
far-reaching economic and social
1:50
consequences rivers are vital arteries
1:53
of trade connecting communities
1:55
Industries and Nations when a river is
1:58
split the flow of goods and servic is
2:00
interrupted affecting local economies
2:02
and global trade networks communities
2:05
that depend on these Rivers for
2:07
transportation and livelihood face
2:09
isolation and industries relying on
2:11
efficient shipping routes incur higher
2:15
delays to address these challenges
2:17
Engineers have historically turned to
2:19
Locks as a solution locks are
2:21
essentially large water filled Chambers
2:24
with Gates on either side a ship enters
2:26
the lock and the water level inside is
2:28
adjusted I either raised or lowered so
2:31
the vessel can move to the next section
2:33
of the River locks date back to ancient
2:36
times with the first notable example
2:38
being the grand Canal's double gate lock
2:40
in China constructed during the 10th
2:43
Century over the centuries this simple
2:46
yet effective technology allowed rivers
2:48
with elevation changes to remain
2:50
navigable however locks have their
2:52
limits especially when dealing with the
2:54
enormous elevation differences created
2:57
by modern Mega dams for example a dam
3:00
with a height equivalent to a 30-story
3:03
building would require multiple locks in
3:05
succession to overcome the elevation
3:07
difference this multilock system
3:10
consumes vast amounts of space costs
3:13
millions of dollars to construct and
3:15
takes hours for ships to Traverse in an
3:18
age of Rapid globalization and
3:20
increasing trade demands this
3:22
inefficiency was no longer acceptable a
3:25
new solution was needed one that could
3:27
handle extreme elevations quickly and
3:30
efficiently ship lifts were developed as
3:32
the next evolutionary step in River
3:34
navigation technology unlike locks which
3:37
rely on a step-by-step process a
3:40
shiplift can handle massive elevation
3:42
changes in a single operation imagine an
3:45
elevator but on a scale so large it can
3:47
carry ships weighing thousands of tons
3:50
the concept of ship lifts is both simple
3:53
and ingenious a ship enters a water
3:56
filled chamber essentially a Giant
4:00
this chamber is then lifted or lowered
4:02
using a system of counterweights cables
4:04
and Motors the beauty of the design lies
4:09
efficiency thanks to Archimedes
4:11
principle the chamber's weight remains
4:13
constant whether it contains just water
4:16
or a ship as well making the lifting
4:19
process surprisingly energy efficient
4:22
one of the most iconic examples of this
4:24
technology is the shiplift at the Three
4:26
Gorges Dam in China this engineering
4:31
2016 can lift ships weighing up to 3,000
4:35
tons to a height of 113 M 370 ft in just
4:40
40 minutes this is a dramatic
4:43
Improvement compared to the traditional
4:45
five-stage lock system which takes 3 to
4:47
4 hours by reducing transit times and
4:50
cutting shipping costs by 25% the Three
4:53
Gorges Dam shiplift has transformed
4:56
trade along the Yi River one of the
4:58
busiest Waterway in the world let's now
5:01
have a look at gubatan shiplift a
5:06
Marvel as impressive as the three
5:08
gorgees Dam lift is it's not the tallest
5:11
shiplift in the world that title belongs
5:14
to the goatan shiplift another
5:16
engineering Masterpiece in China the
5:19
gatan lift elevates ships to an
5:21
astonishing height of 199 M 653 ft
5:27
equivalent to a 60-story building
5:30
to manage this incredible feat the
5:32
system utilizes three interconnected
5:35
lifts each designed to handle different
5:37
elevation changes the first lift is
5:40
variable in height adjusting between 72
5:44
and 79 M depending on Downstream water
5:47
levels the second lift at 127 m is the
5:51
tallest single boat lift in the world
5:54
finally the Upstream lift adjusts up to
5:56
47 m depending on Reservoir levels
6:00
what truly sets gubatan apart is its
6:03
elevated Canal system spanning 2.3 km
6:07
1.4 Mi and suspended over 100 m above
6:11
the ground this network of aqueducts and
6:13
tunnels allows ships to appear as though
6:16
they are floating over mountains this
6:19
breathtaking design has made gubatan not
6:22
just a practical solution for River
6:24
navigation but also a global icon of
6:28
engineering while China leads the world
6:30
in shiplift Innovation other countries
6:33
have also made significant
6:35
contributions in Russia the crask dam
6:38
shiplift has been in operation since
6:41
1976 this unique system uses an
6:44
underwater sled to move ships weighing
6:47
up to 1,500 tons across an elevation of
6:50
101 M 331 ft it remains a vital Link in
6:56
Russia's River Transportation Network in
6:58
Belgium the stpy boat lift connects two
7:02
major river basins and can lift boats
7:06
1,350 tons to a height of 73 M 240 ft
7:12
this structure has revolutionized trade
7:14
routs in the region saving time and
7:17
energy Scotland's ferk wheel is perhaps
7:20
the most visually striking shiplift in
7:21
the world this one of a kind rotating
7:24
lift connects two canals with a height
7:27
difference of 35 m 115 ft its innovative
7:32
design combines functionality with
7:34
Elegance making it a major tourist
7:36
attraction as well as a practical
7:38
navigation tool even in the United
7:40
States new projects like the mobile
7:42
shiplift on the Gulf Coast aim to
7:45
enhance ship building and maritime
7:47
operations once completed it will be the
7:50
largest shiplift in North and South
7:52
America let's now explore how shiplift
7:56
work the core of every shiplift lies in
7:59
its counterweight system by balancing
8:01
the weight of the water filled chamber
8:03
with massive counter weights the lift
8:06
reduces The energy needed to move the
8:08
chamber steel cables powerful Motors and
8:12
advanced computer systems work in
8:14
harmony to ensure smooth and precise
8:17
operation for example the Three Gorges
8:20
Dam lift uses 256 steel cables each
8:24
capable of supporting 460 tons and is
8:27
powered by four Motors each generating
8:30
320 KW of energy these components work
8:34
together to lift ships with Incredible
8:36
efficiency overcoming friction and
8:39
maintaining stability even in changing
8:42
conditions so you see that the ship
8:44
lifts are not just solutions to
8:45
engineering challenges they are symbols
8:47
of human Ingenuity and the Relentless
8:50
pursuit of progress from The Towering
8:53
Heights of the guo batan lift to the
8:55
rotating Elegance of the full Kirk wheel
8:58
these structures redefine what's
9:00
possible they demonstrate that with
9:02
creativity determination and Technical
9:05
expertise we can overcome even the most
9:08
daunting obstacles thank you for joining
9:10
us on this journey into the world of
9:12
shiplift if you found this video
9:14
inspiring don't forget to like share and
9:17
subscribe for more stories about the
9:19
wonders of modern engineering until next
